Retrofit Emission Control Device (RECD) – Clean Air Innovation for Diesel Gensets

Cummins introduces the Retrofit Emission Control Device (RECD) — a revolutionary, filter-less clean air solution for all diesel genset customers. Designed using Electrostatic Precipitation technology, it captures over 70% of particulate matter carbon, significantly improving air quality. Custom-built for Cummins Gensets, these RECDs comply with the National Green Tribunal order O.A. 681/2018, making them a smart and sustainable choice for a cleaner environment.

  • No Manual Testing
  • No Choking
  • Low Maintenance
  • No Filter Replacement
  • No Water Usage
  • No Chemicals Required

Salient Features

  • Energy Efficient: Operates without the need for active regeneration or dependency on high exhaust temperatures, ensuring consistent performance with minimal energy demand.
  • Robust & Versatile: Engineered to perform reliably across a wide range of DG set conditions, with easy adaptability for retrofit installations.
  • Low Flow Restriction: Delivers superior efficiency even at low exhaust flow rates, outperforming conventional filter-based systems.
  • Fuel Efficient: Maintains zero additional fuel consumption, eliminating operational cost overheads.
  • Smart Monitoring: Equipped with advanced IoT-enabled diagnostics and cloud-based alerts for real-time performance tracking and predictive maintenance.
  • Eco-Friendly Reuse: Captured particulate matter can be safely reused in industries such as paints, dyes, and plastics, reducing environmental waste.
  • Durable Design: Designed for long-term durability, ensuring stable performance in all weather and operating conditions.

Working Principle

  • Installed directly after the DG exhaust system, requiring no major modifications.
  • Exhaust gases pass through a high-voltage corona discharge field, initiating the filtration process.
  • Particulate matter (PM) becomes electrically charged and is drawn toward oppositely charged collection electrodes.
  • Charged particles cluster together (agglomerate) into larger particles (above PM10), making them easier to capture.
  • The collected particulate matter is converted into dry powder form for easy handling.
  • Captured particles can be safely reused or disposed of, ensuring zero secondary pollution.
Technology PM Capture Efficiency Initial Cost Operational Cost Prominent Failure Mode Impact on Engine Ease of maintenance Robustness to exhaust challenges
Diesel Oxidation Catalyst (DOC)
20-40%
Low
Negligible
Face plugging
Negligible
Not serviceable
No
DOC + Partial Flow Filters or Partial Oxidation Catalyst (PFF/POC)
60-75%
Moderate to high
Moderate (fuel penalty due to back pressure)
Soot load & thermal event
Variable back pressure
Not serviceable
No
DOC + Diesel Particulate Filter (DPF)
>90%
High
High(fuel penalty due to back pressure)
Soot load & thermal event
Variable back pressure
Ash cleaning soot removal
No
Water/ Solvent Based Exhaust Scrubbers Solution
NA
High
Moderate to high (wash fluid and chemical replenishment)
Fouling and engine hydro-lock
Back pressure due to HE
Complex and frequent service
Probably Yes
Electrostatic Precipitator Technology
80%-90%
Moderate
Negligible
None
Negligible & control parameter
Easy service
Yes
CUMMINS PART NUMBER AX1016671 AX1016672 AX1016673 AX1016674 AX1016675
APPLICABLE TO DG RATING (KVa)
1010
1250
1500
1750
2000
ENVELOPE - L x W x H (mm)
2895 x 2100 x 2871
2895 x 2100 x 3219
2895 x 2970 x2871
2895 x 2970 x 3219
2895 x 3840 x 2871
APPROXIMATE GROSS WEIGHT (kg)
2600
2900
3700
4000
4850
OPERATIONAL POWER CONSUMPTION (kWe)
1.5
2
2
2
3
ENVIRONMENTAL PROTECTION
CANOPY
CANOPY
CANOPY
CANOPY
CANOPY
DESIGN BACK PRESSURE @ RATED (kPa)
<4 kPa
<4 kPa
<4 kPa
<4 kPa
<4 kPa
SOOT COLLECTION FREQUENCY
500 Hrs/Yearly
500 Hrs/Yearly
500 Hrs/Yearly
500 Hrs/Yearly
500 Hrs/Yearly
IoT CAPABILITY
Yes
Yes
Yes
Yes
Yes
